HDLS4SS-9, Lighting Integrator Dataline Switch
SKU: #249036
Part: #HDLS4SS-9
UPC: 754182102815
HDLS4SS-9, Lighting Integrator Dataline Switch
SKU: #249036
Part: #HDLS4SS-9
UPC: 754182102815
Next day delivery
Description
HDLS4SS-9, Lighting Integrator Dataline Switch for Lighting Control
The HDLS4SS-9 Lighting Integrator Dataline Switch by WattStopper is designed for use with LI Complete Control (LICA) and LI DMX (LIDA) panels. It provides flexible and user-friendly lighting control for a single relay or a group of relays within one panel or across a network of panels. This switch is ideal for commercial office buildings and other applications requiring individual occupant lighting control combined with efficient area-wide automated lighting management. It connects via a 4-conductor local dataline, reducing wiring complexity and allowing up to 63 devices per panel.
Specifications
- Manufacturer: WattStopper
- Manufacturer Part #: HDLS4SS-9
- Product Weight: 0.36 lbs
- Color: Gray
- Switch Configuration: 4 individual buttons plus 1 master button
- Mounting: Standard 1-gang switch box
- Dimensions: 4.5” H x 2.75” W x 1.8” D
- Power Consumption: 55 mA
- Operating Temperature Range: 32 to 139°F (0 to 60°C)
- Humidity: 5-95% RH non-condensing
- Compatible Systems: LI Complete Control (LICA) and LI DMX (LIDA) panels
- Data Wiring: 4-conductor local dataline (HDLW4 twisted pair cable)
- Certifications: UL rated
- Warranty: One year
Features
- Pushbutton control for single relays, groups of relays, or channels within Lighting Integrator panel systems
- Bi-color pilot light status LEDs indicating relay states (red = all on, green = mixed state, no color = all off)
- Locator light bar for visibility in the dark
- Screwless wallplate design with removable lens caps for customizable labeling
- Supports smartwiring for flexible programming of individual buttons to relays or relay groups
- Master button programmable via DIP switches with options including Restore/All Off, All On/All Off, or Disabled
- Optional key lock version available for restricted manual control
- Optional cleaning control scenario to enable maintenance lighting without disturbing occupants
- Optional "On Only" setting to prevent accidental turning off of lights
- Available in multiple colors: white, ivory, almond, and gray
