HDLS4SS-7K, Lighting Integrator Dataline Switch
SKU: #249031
Part: #HDLS4SS-7K
UPC: 754182102808
HDLS4SS-7K, Lighting Integrator Dataline Switch
SKU: #249031
Part: #HDLS4SS-7K
UPC: 754182102808
Next day delivery
Description
HDLS4SS-7K Lighting Integrator Dataline Switch
The HDLS4SS-7K Lighting Integrator Dataline Switch by Wattstopper is designed for flexible lighting control within LI Complete Control (LICA) and LI DMX (LIDA) panel systems. This 4-button dataline switch enables precise control of individual relays or groups of relays, either within a single panel or across a network of panels. It supports smartwiring for manual override and pattern-based lighting scenes, making it suitable for advanced lighting solutions in commercial and institutional environments. The switch integrates seamlessly with lighting control panels and automation systems, ideal for electrical distributors and lighting solutions providers.
Specifications
- Manufacturer: Wattstopper
- Manufacturer Part Number: HDLS4SS-7K
- Color: White
- Product Weight: 0.36 lbs
- UPC: 754182102808
- Country of Origin: China
- Compatible with: LI Complete Control (LICA) and LI DMX (LIDA) panels
- Switch Configuration: 4-button dataline switch
- Mounting: Fits standard 1-gang switch boxes
- Dataline Wiring: Uses 4-wire local dataline (red, black, white, blue)
- Smartwire Capability: Supports manual and software smartwiring for relay groups and lighting scenes
- Labeling: Accepts 3/8” wide x 11/16” long (9mm x 30mm) identification labels
- Keyed Version: Available with keyed switch option for authorized control
Features
- Bi-color LED status indicators and locator light for each button
- Supports control of single relay, relay groups, or automation channels across multiple panels
- Smartwire functionality enables flexible programming of lighting control via panel interface or AA-Base automation appliance
- Pattern mode allows configuration of lighting scenes with ON/OFF combinations for relays
- Master button configurable for OFF/RESTORE, ALL ON/ALL OFF, OFF ONLY, or disabled operation via DIP switches
- Cleaning mode disables master button and allows cleaning staff to control lighting without affecting occupant settings
- Mounts in standard electrical boxes with screwless cover plate for easy installation and maintenance
- Available in multiple colors; this model is white
