HDLS4SS-4K Lighting Integrator Dataline Switch

The HDLS4SS-4K Lighting Integrator Dataline Switch by WattStopper is designed for precise lighting control within integrated lighting systems. It supports flexible and user-friendly operation of individual or grouped relays in single or networked lighting control panels. Ideal for electrical distributors and lighting solutions providers, this device interfaces seamlessly with LI Complete Control (LICA) and LI DMX (LIDA) panels, enabling effective management of wire and cable connected lighting circuits.

Specifications

• Manufacturer: WattStopper
• Manufacturer Part #: HDLS4SS-4K
• Product Weight: 0.36 lbs
• Color: Almond
• Country of Origin: China
• UPC Number: 754182102785

Features

• 4-button dataline switch configuration compatible with LI Complete Control and LI DMX panels
• Supports smartwiring to any relay or group of relays within a single panel or across multiple panels
• Bi-color LED status lights and locator light for clear operational feedback
• Accepts standard 3/8” wide (9 mm) identification labels for button customization
• Keyed switch option available for authorized user control
• Mounts in standard 1-gang switch boxes for easy installation
• Compatible with Lighting Integrator networking and automation systems

Downloads & Links

• Installation/Operator
• Specification/Technical
• Data Sheet
