Features

• Designed for use when light, compact grip is desired and where conductor damage is not a factor
• Works on 0.38 to 0.88-Inch (9.65 to 22.35 mm) wire rope cable diameter range with max safe load of 8000 lb (3629 kg)
• Gripping pressure of the knurled jaw is applied to 1/4-Inch (6.35 mm) cable area
• Swing latch helps hold cable in the jaw
• Made in USA

Warnings

• Before each use, clean jaw area and inspect grip for proper operation to avoid slippage.
• When used on/near energized lines, ground, insulate, or isolate grip before pulling.
• Do not exceed rated capacity.
• Always match proper size and type of grip to application.
• Grips are to be used for temporary installation, not for permanent anchorage.

Specifications

• Cable Type: Wire Rope
• Cable Diameter: 0.38" to 0.88" (9.65 to 22.35 mm)
• Jaw Type: Aggressive
• Maximum Safe Load: 8000 lb (3629 kg)
• Type: Haven's Grip
• Hot Latch: No
• Locking Handle: No
• Spring: No
• Swing Latch: Yes
• Height: 1.6920 in
• Width: 4.5000 in
• Depth: 6.7500 in
• Weight: 3.3840 lbs
