GT500R Outdoor Motion Sensor Floodlight – Lighting Solutions

The GT500R by RAB is a weatherproof, corrosion-resistant outdoor motion sensor floodlight designed for automatic lighting control in commercial and residential settings. Ideal for electrical distributors and switchgear suppliers, this product offers reliable motion detection with adjustable sensitivity and time settings, making it suitable for security and convenience lighting applications. The unit accepts PAR-38 lamps (not included) and features a durable die-cast aluminum cover plate for surface or recessed junction box mounting.

Specifications

• Voltage: 120 or 277 volts AC, 60 Hz
• Power Consumption: 4 Watts
• Switching Capacity: 500W @ 120VAC Tungsten, 500W @ 277VAC Tungsten, 600W @ 120VAC Electronic Ballast (LED), 1350W @ 277VAC Electronic Ballast (LED)
• Surge Protection: Withstands up to 6000 volts
• Sensor Detection Zone: 110° view, 50 feet at 8-foot mounting height
• Time Adjustment: 10 seconds to 15 minutes
• Detector Sensitivity: Adjustable from 100% to 50%
• Sensor Housing: Watertight, precision-molded polycarbonate
• Floodlight Construction: Tough, corrosion-resistant polycarbonate floodlights with molded gaskets
• Cover Plate Construction: Die-cast aluminum universal cover plate
• Sockets: Medium base, accepts PAR-38 lamps, 150W max (lamps not included)
• Operating Temperature: -4°F to 104°F (-20°C to 40°C)
• Product Weight: 1.8 lbs
• UL Listed: Suitable for wet locations

Features

• Two weatherproof, corrosion-proof floodlights with molded gaskets
• Protected manual override with auto reset after 6 hours or at dawn, no extra wiring needed
• New vandal resistant grill
• Temperature compensation for accurate sensor performance
• Double look down lens for enhanced detection
• 5-year sensor warranty
• Buy American Act compliance available upon request

Downloads & Links

• Spec Sheet
• Instructions
