FXLED500TB55/D10 LED Floodlight

The FXLED500TB55/D10 is an ultra-high output, high-efficiency LED floodlight designed for general and security lighting of large areas, building façades, signs, and landscapes. It offers advanced thermal management for extended LED and driver lifespan, making it suitable for electrical distributors and lighting solutions providers focusing on wire and cable and switchgear supplier applications.

Specifications

• Manufacturer: RAB
• Input Wattage: 508 watts
• Lumens: 61,509 lumens
• Efficacy: 121 lumens per watt
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 73 CRI
• Lens Material: Clear Glass
• Weight: 71.7 lbs
• Ambient Temperature: Suitable for up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• NEMA Beam Spread: 5H x 5V
• LED Lifespan: 100,000 hours (based on IES LM-80 and TM-21 calculations)
• IP Rating: IP66 for dust and water protection
• Housing: Die-cast aluminum with lens frame
• Mounting: Heavy-duty Trunnion mount with stainless steel hardware
• Vibration Rating: 2G per ANSI C136.31
• Surge Protection: 4kV

Features

• Equivalent to 1500W Metal Halide floodlights
• Advanced thermal design with external Air-Flow fins for superior heat dissipation
• Multip-chip, high-output, long-life LEDs with color stability warranty limiting shift to 200K over 5 years
• High durability bronze finish formulated for long-lasting color
• Mercury and UV free, RoHS-compliant components
• Constant current driver, Class 1, universal voltage 120-277V, 50/60 Hz
• Suitable for mounting within 1.2m (4ft) of the ground and wet locations
• 5-Year warranty covering light output, color stability, driver performance, and fixture finish
• American Bureau of Shipping (ABS) certified for use on Mobile Offshore Drilling Units and shipping vessels
