Features

• 66% energy cost savings vs. HID
• NEMA Type - 6H x 6V
• Air-Flow" technology heat dissipation
• 100,000-hour LED lifespan
• 5-Year, No-Compromise Warranty
• Equivalency
• Warranty
• Buy American Act Compliance

Specifications

• Weight: 22.8 lbs

Compliance

• UL Listed: Suitable for wet locations. Suitable for mounting within 1.2m (4ft) of the ground.
• IESNA LM-79 & IESNA LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
• DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities.

Performance

• Watts: 150W
• Color Temp: 5000K (Cool)
• Lumens: 20,686 lm
• Efficacy: 126 lm/W
• Color Accuracy: 72 CRI
• Type: Constant Current
• 120V: 1.39A
• 208V: 0.80A
• 240V: 0.70A
• 277V: 0.60A
• Input Watts: 164W

LED Characteristics

• LEDs: Long-life, high-efficacy, surface-mount LEDs
• Color Stability: LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

• IP Rating: Ingress protection rating of IP66 for dust and water
• EPA: 2
• Ambient Temperature: Suitable for use in up to -40°C (-40°F) to 40°C (104°F)
• Lens: Tempered glass lens included
• Housing: Die-cast aluminum housing and door frame
• Mounting: Heavy-duty slipfitter for 2 3/8"OD pipe
• Finish: Formulated for high durability and long-lasting color
• Tilt Increment: Rotates in 6 degree increments

Electrical

• Driver: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 1.39A, 208V: 0.81A, 240V: 0.70A, 277V: 0.60A
• THD: 1.95% at 120V, 8.2% at 277V
• Power Factor: 99.9% at 120V, 97.6% at 277V
• Note: All values are typical (tolerance +/- 10%)
• Photocell: 120-277V Twistlock photocell included. Photocell is compatible with 120-277V.
