FXLED150SF/PCT LED Flood Light by RAB – High-Efficiency Architectural Lighting

The FXLED150SF/PCT is a high-performance LED flood light designed for architectural and outdoor applications. Manufactured by RAB, this fixture delivers superior lighting solutions suitable for electrical distributors and switchgear suppliers seeking reliable, energy-efficient lighting. It features a tempered glass lens and operates efficiently in ambient temperatures as low as -40 degrees Celsius, making it ideal for demanding environments.

Specifications

• Manufacturer: RAB
• Model Number: FXLED150SF/PCT
• Input Wattage: 164 watts
• Lumens Output: 20,686 lumens
• Efficacy: 126 lumens per watt
• Color Temperature: 5000 kelvins
• Color Accuracy (CRI): 72
• Lens Material: Tempered Glass
• Operating Ambient Temperature: -40 degrees Celsius
• Product Weight: 22.8 lbs
• UPC: 019813399164

Features

• High lumen output with premium efficacy for energy savings
• Durable tempered glass lens for enhanced protection and longevity
• Wide color temperature suitable for daylight applications
• Stable performance in extreme cold environments down to -40°C
• Designed for easy installation with slipfitter and trunnion mounting options
• 0-10V dimmable driver compatible with universal voltage (120-277V, 50/60 Hz)
