FXLED125SFN LED Flood Light for Electrical Distribution and Lighting Solutions

The FXLED125SFN by RAB is a high-performance LED flood light designed for outdoor architectural flood and spot lighting applications. It is suitable for electrical distributors and lighting solution providers seeking efficient, durable, and precise illumination. This fixture operates on a universal voltage range of 120V to 277V, 50/60 Hz, making it compatible with a wide range of electrical systems. It delivers high lumen output with excellent efficacy, ideal for wire and cable installations and switchgear supplier projects requiring reliable and energy-efficient lighting.

Specifications

• Manufacturer: RAB
• Model Number: FXLED125SFN
• Input Wattage: 137 watts
• Lumens: 18,522 lumens
• Efficacy: 135 lumens per watt
• Color Temperature: 4000 kelvins
• Color Accuracy (CRI): 74
• Lens Material: Tempered Glass
• Product Weight: 27.1 lbs
• Operating Ambient Temperature: Up to 104°F
• Minimum Starting Temperature: -40°C
• Voltage Range: 120V-277V, 50/60Hz
• Beam Angle (50%): Horizontal 67.3°, Vertical 90.9°
• Field Angle (10%): Horizontal 101.4°, Vertical 119.2°

Features

• High lumen output with 18,522 lumens for bright, efficient illumination
• Energy efficient with 135 lumens per watt efficacy
• Durable tempered glass lens for protection and longevity
• Wide operating temperature range suitable for harsh outdoor environments
• Universal voltage driver for versatile installation (120V-277V, 50/60 Hz)
• Excellent color rendering with a CRI of 74 for accurate color representation
• Low total harmonic distortion (THD) enhancing power quality and reducing electrical noise
• Adjustable mounting options including slipfitter and trunnion mounts for flexible installation

Downloads & Links

• LM79
• Instructions
• Spec Sheet
