FXLED105SFN LED Flood Light

The FXLED105SFN is a high-performance LED flood light designed for outdoor lighting applications. Ideal for electrical distributors and lighting solution providers, this fixture offers efficient illumination with a focus on durability and energy savings. It features a heavy-duty slipfitter mount suitable for 2 3/8" OD pipe installations, making it compatible with various commercial and industrial outdoor lighting setups. The fixture is well-suited for environments requiring robust wire and cable solutions and is designed to operate reliably in ambient temperatures up to 104°F (40°C).

Specifications

• Input Wattage: 111 watts
• Lumens: 14,294 lumens
• Efficacy: 129 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 74 CRI (Color Rendering Index)
• Lens Material: Tempered Glass
• Product Weight: 27.7 lbs
• Maximum Ambient Temperature: 104 degrees Fahrenheit
• Minimum Starting Temperature: -40 degrees Celsius
• Mounting: Heavy-duty slipfitter for 2 3/8" OD pipe
• IP Rating: IP66 for dust and water protection
• Housing: Die-cast aluminum housing and door frame
• Reflector: Specular, vacuum-metalized polycarbonate
• Lifespan: 100,000 hours (based on IES LM-80 and TM-21 calculations)

Features

• 66% energy cost savings compared to HID lighting
• NEMA Beam Spread: 6H x 6V for optimized light distribution
• Superior thermal management with external "Air-Flow" fins
• High durability with formulated finish for long-lasting color
• Mercury and UV free, RoHS-compliant components
• 3-step MacAdam Ellipse binning for consistent color uniformity
• Rotates in 6-degree increments for precise aiming
• UL Listed and suitable for wet locations and ground mounting
• DLC Listed as an ultra-efficient premium product qualifying for highest tier rebates
• 5-year warranty covering light output, color stability, driver performance, and fixture finish
