FXLED105SF/PCT LED Flood Light

The FXLED105SF/PCT is a high-efficiency LED flood light designed for outdoor lighting applications. It provides superior illumination with 14,029 lumens output at 109 watts input power, making it suitable for electrical distributors and lighting solution providers seeking reliable, energy-saving fixtures. This product features a durable die-cast aluminum housing and tempered glass lens, engineered for wet locations and harsh environments with an IP66 ingress protection rating. Ideal for wire and cable installations requiring robust lighting and switchgear suppliers needing dependable outdoor fixtures.

Specifications

• Manufacturer: RAB
• Manufacturer Part #: FXLED105SF/PCT
• Input Wattage: 109 watts
• Lumens: 14,029 lumens
• Efficacy: 128 lumens per watt
• Color Temperature: 5000 kelvins
• Color Accuracy: 72 CRI
• Lens Material: Tempered Glass
• Ambient Temperature Range: -40°C to 40°C (-40°F to 104°F)
• Product Weight: 27.7 lbs
• IP Rating: IP66 (dust and water resistant)
• Mounting: Heavy-duty slipfitter for 2 3/8" OD pipe
• Housing: Die-cast aluminum
• Lifespan: 100,000 hours (L70)
• Driver Type: Constant Current, Class 2, 120-277V, 50/60 Hz

Features

• 66% energy cost savings compared to 320W Metal Halide
• NEMA Type 6H x 6V rating
• "Air-Flow" technology for heat dissipation
• 5-Year, no-compromise warranty covering performance and finish
• 120-277V Twistlock photocell included for automatic operation
• Rotates in 6-degree increments for precise aiming
• Color temperature stability with less than 200K shift over 5 years
