FXL400TQTW High-Performance HID Floodlight

The FXL400TQTW is a specification-grade 400-watt HID floodlight designed for architectural and commercial lighting applications. It provides high-intensity illumination with 50,000 lumens output and an efficacy of 107 lumens per watt, making it suitable for use by electrical distributors and lighting solutions providers targeting outdoor and wet location installations. The floodlight features a precision die-cast aluminum housing with multiple mounting options including wall bracket, trunnion, and slipfitter, offering versatility for various installation needs.

Specifications

• Input Wattage: 464 watts
• Lumens: 50,000 lumens
• Efficacy: 107 lumens per watt
• Lens Material: Thermal tempered shock resistant glass, 3/16" thick
• Housing: Precision die-cast aluminum
• Reflector: Anodized aluminum, field adjustable beam spread
• Finish: Durable polyester powder coating
• Socket: HID Porcelain 4kv pulse rated with nickel plated screw shell
• Weight: 36.3 lbs
• EPA (Effective Projected Area): Maximum 2.0
• UL Listed: Suitable for wet locations and ground mounting

Features

• Integra hood glare shield for controlled lighting
• Silicone gasket for weatherproof sealing and easy relamping
• Precision die-cast aluminum housing and lens frame with high durability
• Two field adjustable socket positions for fine tuning beam spread
• Fins for heat dissipation to extend lamp and ballast life
• Hinged lens frame with Phillips head screws for secure and easy access
• Multiple mounting options: wall bracket, trunnion, and slipfitter
