Fuse GDL - Time-Delay 250V 1A 6x32mm, 1/4" X 1-1/4"
SKU: #196384
Part: #GDL1
UPC: 782001763206
Fuse GDL - Time-Delay 250V 1A 6x32mm, 1/4" X 1-1/4"
SKU: #196384
Part: #GDL1
UPC: 782001763206
Description
Fuse GDL - Time-Delay 250V 1A 6x32mm, 1/4" X 1-1/4" Electrical Fuse
This Mersen Fuse GDL is a time-delay glass fuse designed for electrical protection applications requiring reliable current interruption up to 250 volts. Suitable for use by electrical distributors and switchgear suppliers, it provides overcurrent protection in lighting solutions, wire and cable systems, and other electrical circuits. Its compact 1/4" x 1-1/4" size and clip mounting type enable easy installation in various electrical assemblies.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: GDL1
- Amperage: 1 amperes
- Voltage Rating: Up to 250V
- Fuse Type: Time Delay
- Material: Glass
- Dimensions: 0.25 in (Diameter) x 1.25 in (Length)
- Mounting Type: Clip
- Product Weight: 0.0100 lbs
- Country of Origin: China
Features
- Time-delay action allows temporary current surges without fuse interruption
- Glass body enables visual inspection of fuse element condition
- Compact 6x32mm (1/4" x 1-1/4") size for standardized electrical applications
- Clip mounting facilitates secure and easy installation
- UL Listed and CSA Certified for safety and compliance (per datasheet on page 1)
