Fuse GDL - Time-Delay 125V 10A 6x32mm, 1/4" X 1-1/4"
SKU: #196394
Part: #GDL10
UPC: 782001763381
Fuse GDL - Time-Delay 125V 10A 6x32mm, 1/4" X 1-1/4"
SKU: #196394
Part: #GDL10
UPC: 782001763381
Description
Fuse GDL - Time-Delay 125V 10A 6x32mm, 1/4" X 1-1/4" – Time-Delay Fuse
This Mersen Fuse GDL is a time-delay glass fuse designed for electrical protection in lighting solutions, wire and cable systems, and as part of switchgear assemblies. Rated for up to 125 volts and 10 amperes, it provides reliable circuit protection with a clip mounting type, suitable for applications requiring delayed response to transient surges.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: GDL10
- Voltage Rating: 125 V
- Amperage: 10 amperes
- Fuse Type: Time-Delay
- Material: Glass
- Dimensions: 0.25 in (diameter) x 1.25 in (length)
- Mounting Type: Clip
- Product Weight: 0.0100 lbs
- Country of Origin: China
Features
- Glass body construction for visual fuse status inspection
- Time-delay action to allow temporary current surges without blowing
- Standard 1/4" x 1-1/4" size for compatibility with common fuse holders
- UL Listed and CSA certified for safety and compliance (per datasheet on page 1)
