Fuse Bases 600V 30A Midget 2-pole Tin-Plate Copper Copper Box – Electrical Fuse Bases

Mersen Fuse Bases are designed for 600V electrical applications, accommodating all 30 ampere 1-1/2” x 13/32” midget fuses. These 2-pole fuse bases are suitable for use in electrical distribution and lighting solutions, providing reliable wire and cable connections with copper box connectors. The product is ideal for electrical distributors and switchgear suppliers requiring durable fuse blocks with high conductivity and verified dielectric strength.

Specifications

• Amperage: 30 amperes
• Voltage Rating: 600 VAC / DC
• Number of Poles: 2-pole
• Material: Glass Filled Polycarbonate (GFPC)
• Connection Type: Copper Box
• Mounting: Screw Mount or DIN Rail
• Frequency: 50 hertz
• Maximum Operating Temperature: 80 degrees Celsius
• Dimensions (L x W x H): 3.04 in x 1.6 in x 1.31 in
• Product Weight: 0.23 lbs
• Country of Origin: Mexico
• Manufacturer: Mersen
• Manufacturer Part #: 30352

Features

• Accommodates all 30 ampere 1-1/2” x 13/32” midget fuses
• Insulators made of glassfilled polycarbonate with dielectric strength exceeding 2500V
• High conductivity tin-plated copper alloy fuse clips
• Unique adder block design for forming multi-pole segmented blocks
• Choice of box, screw, or pressure-plate connectors for a wide range of stranded or solid copper wire
• UL recognized and CSA certified for safety and compliance
