Fuse Bases 600V 30A Class CC 2-pole Tin-Plate CU Screw with Reinforced Clip

This Mersen fuse base is designed for use with 30 ampere Class CC fuses, suitable for electrical distributors and switchgear suppliers requiring reliable fuse holders for wire and cable protection. It accommodates all 30 ampere Class CC fuses and features screw mounting or DIN rail installation options. The product is constructed with glass-filled polycarbonate insulators providing dielectric strength exceeding 2500V, and high conductivity tin-plated copper alloy fuse clips ensure optimal electrical performance. This 2-pole fuse base supports 600V AC/DC applications at 50 Hz frequency and is rated for a maximum operating temperature of 80°C.

Specifications

• Amperage: 30 amperes
• Voltage Rating: 600V AC/DC
• Number of Poles: 2-pole
• Material: Glass Filled Polycarbonate
• Connection Type: Screw with Reinforced Clip
• Mounting: Screw Mount or DIN Rail
• Frequency: 50 hertz
• Maximum Operating Temperature: 80 degrees Celsius
• Dimensions (L x W x H): 3.04 in x 0.85 in x 1.31 in
• Product Weight: 0.2300 lbs
• Country of Origin: Mexico
• Manufacturer Part Number: 30312R

Features

• Accommodates all 30 ampere Class CC fuses
• Glass-filled polycarbonate insulators with dielectric strength over 2500V
• High conductivity tin-plated copper alloy fuse clips
• Unique adder block design allows snap-on assembly for multi-pole configurations
• Choice of box, screw, or pressure-plate connectors for stranded or solid copper wire
• UL recognized and CSA certified for safety compliance
