Fuse Amp-Trap® 600V 8A Fast-Acting Class K5 OTS Series Fuse

The Fuse Amp-Trap® 600V 8A Fast-Acting Class K5 OTS Series is designed for low-cost protection of feeders and branch circuits in residential and small commercial electrical installations. It is suitable for applications including resistive heating, lighting, and other non-motor loads. This fuse safely interrupts short circuit currents up to 50,000 amperes, making it a reliable choice for electrical distributors and switchgear suppliers focused on wire and cable protection and lighting solutions.

Specifications

• Amperage Rating: 8 A
• Voltage Rating: 600 V AC
• Interrupt Rating: 50 kA
• Fuse Class: Class K5
• Dimensions: Length 5 in, Diameter 0.81 in
• Mounting Type: Clip
• Connection Type: Ferrule
• Insulation Material: Paper
• Product Weight: 0.1100 lbs
• Manufacturer Part Number: OTS8
• Application: Feeders, Branch circuits, Resistive heating, Residential and small commercial installations

Features

• One-time OTS general purpose fuse providing economical protection
• Fast-acting design for effective interruption of non-motor loads
• Capable of interrupting available short circuit currents up to 50,000 amperes
• Not a rejection fuse; replacement fuses must match or exceed original interrupting ratings
