Fuse Amp-Trap® 600V 60A Fast-Acting Class K5 OTS Series
SKU: #197037
Part: #OTS60
UPC: 782001700805
Fuse Amp-Trap® 600V 60A Fast-Acting Class K5 OTS Series
SKU: #197037
Part: #OTS60
UPC: 782001700805
Description
Fuse Amp-Trap® 600V 60A Fast-Acting Class K5 OTS Series Fuse
The Fuse Amp-Trap® 600V 60A Fast-Acting Class K5 OTS Series is designed for low-cost protection of feeders and branch circuits in residential and small commercial electrical installations. It is suitable for use in lighting solutions, resistive heating, and other non-motor load applications. This fuse safely interrupts short circuit currents up to 50,000 amperes, making it a reliable component for electrical distributors and switchgear suppliers handling wire and cable systems.
Specifications
- Amperage Rating: 60 A
- Voltage Rating: 600 V AC
- Interrupt Rating: 50 kA
- Fuse Class: Class K5
- Dimensions: Length 5.5 in, Diameter 1.06 in, Width 1.06 in, Height 1.06 in
- Mounting Type: Clip
- Connection: Ferrule
- Insulation Material: PolyTube
- Product Weight: 0.2150 lb
- Manufacturer: Mersen
- Manufacturer Part Number: OTS60
Features
- One-time general purpose fuse providing fast-acting protection
- Designed for feeder and branch circuits serving lighting, heating, and other non-motor loads
- Safe interruption of short circuit currents up to 50,000 amperes
- Non-rejection fuse; replacement fuses must match or exceed original interrupting ratings
- PolyTube insulation for electrical safety and durability
