Fuse Amp-Trap® 600V 30A Fast-Acting Class K5 OTS Series
SKU: #196960
Part: #OTS30
UPC: 782001700744
Fuse Amp-Trap® 600V 30A Fast-Acting Class K5 OTS Series
SKU: #196960
Part: #OTS30
UPC: 782001700744
Description
Fuse Amp-Trap® 600V 30A Fast-Acting Class K5 OTS Series Fuse
The Fuse Amp-Trap® 600V 30A Fast-Acting Class K5 OTS Series is designed for low-cost protection of feeders and branch circuits in residential and small commercial electrical installations. It is suitable for resistive heating, lighting, and other non-motor loads. This fuse safely interrupts short circuit currents up to 50,000 amperes, making it a reliable component for electrical distributors, lighting solutions providers, wire and cable specialists, and switchgear suppliers.
Specifications
- Amperage Rating: 30 A
- Voltage Rating: 600 V AC
- Interrupt Rating: 50 kA
- Fuse Class: Class K5
- Mounting Type: Clip
- Connection: Ferrule
- Dimensions: Length 5 in, Diameter 0.81 in, Width 0.81 in, Height 0.81 in
- Insulation Material: Paper
- Product Weight: 0.1100 lb
- Manufacturer Part #: OTS30
- Manufacturer: Mersen
Features
- One-time general purpose fuse providing fast-acting protection
- Designed for feeders and branch circuits serving lighting, heating, and resistive loads
- Interrupts available short circuit currents up to 50,000 amperes
- Not a rejection fuse; replacement fuses must have equal or higher interrupting ratings
- Clip mounting for easy installation
