Fuse Amp-Trap® 300V 400A Fast-Acting Class T A3T Series
SKU: #194413
Part: #A3T400
UPC: 782001890285
Fuse Amp-Trap® 300V 400A Fast-Acting Class T A3T Series
SKU: #194413
Part: #A3T400
UPC: 782001890285
Description
Fuse Amp-Trap® 300V 400A Fast-Acting Class T A3T Series Fuse
The Fuse Amp-Trap® 300V 400A Fast-Acting Class T A3T Series fuse is designed for use in load centers, panelboards, switchboards, circuit breakers, and metering centers. As a reliable electrical component, it offers high current-limitation and compact size, making it suitable for demanding electrical distribution and lighting solutions applications. This fuse is ideal for electrical distributors and switchgear suppliers requiring precise and secure overcurrent protection.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: A3T400
- Fuse Class: Class T
- Amperage Rating: 400 A
- Interrupt Rating: 200 kA
- Voltage Rating: 300 V
- Dimensions (L x W x H): 2.75 in x 1.33 in x 1.33 in
- Connection Type: Blade
- Mounting Type: Bolted
- Insulation Material: GMG (Glass Melamine)
- Product Weight: 0.2720 lbs
Features
- Fast-acting fuse with high current-limitation for enhanced protection
- Compact physical size prevents substitution with lower voltage or current-limiting fuses
- Glass melamine body ensures superior dimensional stability
- Catalog numbers permanently stamped into blades for easy identification
