Fuse Amp-Trap® 300V 30A Fast-Acting Class T A3T Series
SKU: #194397
Part: #A3T30
UPC: 782001890094
Fuse Amp-Trap® 300V 30A Fast-Acting Class T A3T Series
SKU: #194397
Part: #A3T30
UPC: 782001890094
Description
Fuse Amp-Trap® 300V 30A Fast-Acting Class T A3T Series
The Fuse Amp-Trap® 300V 30A Fast-Acting Class T A3T Series by Mersen is designed for precise overcurrent protection in electrical distribution systems. This fuse is suitable for use in load centers, panelboards, switchboards, circuit breakers, and metering centers, making it an essential component for electrical distributors and switchgear suppliers. It features a compact size combined with high current-limiting capability to enhance safety and reliability in wire and cable applications.
Specifications
- Amperage Rating: 30 A
- Voltage Rating: 300 V
- Interrupt Rating: 200 kA
- Fuse Class: Class T
- Dimensions (L x W x H): 0.88 in x 0.41 in x 0.41 in
- Diameter: 0.41 inches
- Product Weight: 0.0120 lbs
- Connection: Ferrule
- Mounting Type: Clip
- Insulation Material: Glass Melamine (GMG)
- Manufacturer Part Number: A3T30
Features
- Fast-acting fuse with high current-limitation for enhanced protection
- Compact physical size prevents substitution with lower-rated fuses
- Glass melamine body ensures superior dimensional stability
- Catalog numbers permanently stamped on blades for easy identification
- Designed for use in a variety of electrical distribution equipment
