Fuse Amp-Trap 2000® 600V 45A Time-Delay Class J AJT Series Smart-Spot
SKU: #195481
Part: #AJT45
UPC: 782001962340
Fuse Amp-Trap 2000® 600V 45A Time-Delay Class J AJT Series Smart-Spot
SKU: #195481
Part: #AJT45
UPC: 782001962340
Description
Fuse Amp-Trap 2000® 600V 45A Time-Delay Class J AJT Series Smart-Spot
The Amp-Trap 2000® AJT fuse is designed for motor circuits, mains feeders, branch circuits, lighting, heating, general loads, transformers, control panels, and circuit breaker back-up applications. This Class J time-delay fuse offers IEC Type 2 no damage protection with advanced material technology, providing superior current-limiting capabilities while requiring half the mounting space of traditional 600VAC Class RK fuses. Its SmartSpot visual open fuse indicator enhances operational awareness, making it suitable for electrical distributors and switchgear suppliers focused on reliable lighting solutions and wire and cable protection.
Specifications
- Manufacturer: Mersen
- Amperage Rating: 45 A
- Voltage Rating: 600 V AC
- Interrupt Rating: 200 kA
- Fuse Class: Class J
- Frequency: 50 hertz
- Dimensions (L x W x H): 2.38 in x 1.06 in x 1.06 in
- Diameter: 1.06 inches
- Mounting Type: Clip
- Connection Type: Ferrule
- Insulation Material: GMG
- Product Weight: 0.1670 lbs
- Manufacturer Part Number: AJT45
Features
- SmartSpot visual open fuse indicator for quick identification of fuse operation
- Time-delay characteristics ideal for motor and transformer inrush currents
- Advanced materials providing IEC Type 2 no damage protection
- Compact size requiring half the mounting space of Class RK fuses
- Superior current-limiting ability to reduce peak currents
- Orange label for fast visual identification
- Durable fiber glass body ensuring dimensional stability in industrial environments
- Recommended for reducing arc flash energy and suitable for Class I Division 2 hazardous locations
- UL and CSA listed for safety and performance compliance
