Fuse Amp-Trap 2000® 600V 3A Time-Delay Class CC ATQR Series
SKU: #195970
Part: #ATQR3
UPC: 782001906535
Fuse Amp-Trap 2000® 600V 3A Time-Delay Class CC ATQR Series
SKU: #195970
Part: #ATQR3
UPC: 782001906535
Description
Fuse Amp-Trap 2000® 600V 3A Time-Delay Class CC ATQR Series
The Fuse Amp-Trap 2000® ATQR Series by Mersen is a Class CC time-delay fuse designed for electrical distribution systems requiring reliable protection. It is specifically suited for control transformers, solenoids, inductive loads, lighting, heating, and general-purpose loads. This fuse provides superior protection for branch circuits by accommodating high inrush currents typical in such applications. It is ideal for electrical distributors and switchgear suppliers seeking durable and precise wire and cable protection solutions.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: ATQR3
- Fuse Class: Class CC
- Amperage Rating: 3 A
- Voltage Rating: 600 V
- Interrupt Rating: 200 kA
- Frequency: 50 hertz
- Dimensions (L x W x H): 1.5 in x 0.41 in x 0.41 in
- Diameter: 0.41 inches
- Mounting Type: Clip
- Connection Type: Ferrule
- Insulation Material: GMG
- Product Weight: 0.0170 lbs
Features
- Time-delay characteristics suitable for high inrush currents
- Compact small-dimension design for space-saving installations
- Provides superior protection for branch circuits in electrical distribution systems
- Clip mounting for easy installation and replacement
