Fuse Amp-Trap 2000® 600V 1.4A Time-Delay Class CC ATQR Series
SKU: #195865
Part: #ATQR1-4/10
UPC: 782001906405
Fuse Amp-Trap 2000® 600V 1.4A Time-Delay Class CC ATQR Series
SKU: #195865
Part: #ATQR1-4/10
UPC: 782001906405
Description
Fuse Amp-Trap 2000® 600V 1.4A Time-Delay Class CC ATQR Series
The Mersen Amp-Trap 2000® ATQR series fuse is designed for protection in electrical distribution systems, particularly suitable for control transformers, solenoids, inductive loads, lighting, heating, and general-purpose applications. This Class CC time-delay fuse accommodates high inrush currents, providing reliable branch circuit protection for wire and cable systems used by electrical distributors and switchgear suppliers.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: ATQR1-4/10
- Fuse Class: Class CC
- Voltage Rating: 600 V
- Amperage Rating: 1.4 A
- Interrupt Rating: 200 kA
- Frequency: 50 hertz
- Dimensions (L x W x H): 1.5 in x 0.41 in x 0.41 in
- Diameter: 0.41 inches
- Mounting Type: Clip
- Connection Type: Ferrule
- Insulation Material: GMG
- Product Weight: 0.0170 lbs
Features
- Time-delay characteristics ideal for high inrush currents of control transformers and inductive loads
- Compact small-dimension design for space-efficient installations
- Provides superior protection for branch circuits in electrical distribution systems
- Clip mounting allows for easy installation and replacement
