Fuse Amp-Trap 2000® 600V 0.8A Time-Delay Class CC ATQR Series
SKU: #196084
Part: #ATQR8/10
UPC: 782001906368
Fuse Amp-Trap 2000® 600V 0.8A Time-Delay Class CC ATQR Series
SKU: #196084
Part: #ATQR8/10
UPC: 782001906368
Description
Fuse Amp-Trap 2000® 600V 0.8A Time-Delay Class CC ATQR Series
The Mersen Amp-Trap 2000 ATQR Series fuse is designed for protection of branch circuits in electrical distribution systems. It features time-delay characteristics ideal for handling high inrush currents typical of control transformers, solenoids, inductive loads, lighting, heating, and general-purpose loads. This fuse is suitable for electrical distributors and switchgear suppliers looking for reliable and compact overcurrent protection solutions.
Specifications
- Voltage Rating: 600 V
- Amperage Rating: 0.8 A
- Interrupt Rating: 200 kA
- Frequency: 50 hertz
- Fuse Class: Class CC
- Dimensions: Length 1.5 in, Width 0.41 in, Height 0.41 in
- Diameter: 0.41 inches
- Mounting Type: Clip
- Connection: Ferrule
- Insulation Material: GMG
- Product Weight: 0.0170 lbs
- Manufacturer Part Number: ATQR8/10
Features
- Small-dimension fuse with time-delay characteristics
- Provides superior protection for branch circuits in electrical distribution
- Designed to handle high inrush currents from inductive loads like control transformers and solenoids
- Compact size facilitates installation in limited space applications
