Fuse Amp-Trap 2000® 600V 0.75A Time-Delay Class CC ATQR Series
SKU: #196005
Part: #ATQR3/4
UPC: 782001906351
Fuse Amp-Trap 2000® 600V 0.75A Time-Delay Class CC ATQR Series
SKU: #196005
Part: #ATQR3/4
UPC: 782001906351
Description
Fuse Amp-Trap 2000® 600V 0.75A Time-Delay Class CC ATQR Series
The Mersen Fuse Amp-Trap 2000® ATQR Series is a time-delay Class CC fuse designed for protection in electrical distribution systems. It is specifically engineered to handle the high inrush currents of control transformers, solenoids, inductive loads, lighting, heating, and general-purpose loads. This fuse is suitable for use by electrical distributors, lighting solutions providers, wire and cable specialists, and switchgear suppliers requiring reliable branch circuit protection.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: ATQR3/4
- Fuse Class: Class CC
- Voltage Rating: 600 V
- Amperage Rating: 0.75 A
- Interrupt Rating: 200 kA
- Frequency: 50 hertz
- Dimensions (L x W x H): 1.5 in x 0.41 in x 0.41 in
- Diameter: 0.41 inches
- Weight: 0.0170 lbs
- Mounting Type: Clip
- Connection: Ferrule
- Insulation Material: GMG
Features
- Time-delay characteristic ideal for high inrush currents
- Small dimension design for compact installations
- Provides superior protection for branch circuits in electrical distribution systems
- Suitable for control transformers, solenoids, inductive, lighting, heating, and general-purpose loads
