Fuse Amp-Trap 2000® 600V 0.6A Time-Delay Class CC ATQR Series
SKU: #196055
Part: #ATQR6/10
UPC: 782001906344
Fuse Amp-Trap 2000® 600V 0.6A Time-Delay Class CC ATQR Series
SKU: #196055
Part: #ATQR6/10
UPC: 782001906344
Description
Fuse Amp-Trap 2000® 600V 0.6A Time-Delay Class CC ATQR Series
The Mersen Amp-Trap 2000® ATQR Series fuse is designed for reliable protection of branch circuits in electrical distribution systems. This Class CC time-delay fuse is optimized for controlling high inrush currents typical of control transformers, solenoids, and inductive loads, as well as lighting, heating, and general-purpose loads. It is suitable for use by electrical distributors and switchgear suppliers requiring compact, high-performance wire and cable protection solutions.
Specifications
- Amperage Rating: 0.6 A
- Voltage Rating: 600 V
- Interrupt Rating: 200 kA
- Frequency: 50 hertz
- Fuse Class: Class CC
- Mounting Type: Clip
- Connection: Ferrule
- Dimensions (L x W x H): 1.5 in x 0.41 in x 0.41 in
- Diameter: 0.41 inches
- Product Weight: 0.0170 lbs
- Insulation Material: GMG
- Manufacturer Part Number: ATQR6/10
Features
- Time-delay characteristic ideal for high inrush currents of control transformers and solenoids
- Small dimension design for space-saving installation in electrical panels
- Provides superior protection for branch circuits in electrical distribution systems
- Clip mounting for easy installation and replacement
