Features

• Corrosion Resistant Ideal for Indoor and Outdoor Installations
• Weatherproof, Rain Tight and Dust Tight When Used with Cast Gasketed Covers
• Malleable Iron for High Tensile Strength and Ductility Provides Greater Resistance to Impact and Shock
• Both Malleable Iron and Aluminum Boxes have Ridge Top Construction for Positive Cover/Gasket/Box Fit
• Accurately Tapped, Tapered Threads for Tight, Rigid Joints, Ground Continuity
• Internal Grounding Screws Standard
• Smooth, Rounded Integral Bushing in Each Hub Protects Conductor Insulation

Additional Information

• Includes Stainless Steel Screw
• Used On IMC/Rigid Metal Conduit
• Application Commercial/Industrial, Switch and Receptacle, Special Conduit Entrance Arrangement
• Applicable Standard NEC/CEC, NEMA FB-1

Specifications

• Height: 5.88 Inch
• Width: 2.81 Inch
• Depth: 2 Inch
• Capacity: 18 Cubic Inch
• Number of Gangs: 1
• Number of Hubs: 2
• Hub Size: 3/4 Inch
• Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron
• Shape: Shallow
• Configuration Type: FSS
• Mounting Hardware: Not Included
• Approval: UL 514A
• Series/Model: FS
