Description
FFLED80/D10 LED Floodlight
The FFLED80/D10 is a rectangular LED floodlight designed to replace 250W metal halide fixtures, offering an energy-efficient lighting solution suitable for building façades, sign lighting, landscape lighting, and instant-on security lighting. This product is ideal for electrical distributors and lighting solutions providers seeking durable, high-performance outdoor lighting with advanced thermal management and long operational life.
Specifications
- Manufacturer: RAB
- Input Wattage: 87 watts
- Lumens: 10,382 lumens
- Efficacy: 119 lumens per watt
- Color Temperature: 5000 kelvins (Cool)
- Color Accuracy: 72 CRI
- Product Weight: 11.5 lbs
- Minimum Starting Temperature: -40 degrees Celsius
- Ambient Temperature Rating: 104 degrees Fahrenheit
- LED Lifespan: 100,000 hours (based on IES LM-80 and TM-21 calculations)
- Driver Type: Constant Current, Class 2, 100-277V, 50/60 Hz, 6 kV surge protection
- Dimming: 0-10V dimming down to 10%
- IP Rating: IP66 for dust and water protection
- Housing: Die-cast aluminum with external Air-Flow fins for superior heat sinking
- Mounting: 1/2" threaded arm with heavy-duty mounting arm and stainless steel screw
- Reflector: Specular polycarbonate
- Gaskets: High-temperature silicone
- Finish: Durable bronze color
- NEMA Beam Spread: 7H x 6V
- Equivalency: Replaces 250W Metal Halide
Features
- Ultra-efficient LED and optical design
- Patent-pending "Air-Flow" technology for enhanced thermal management and extended LED and driver lifespan
- Suitable for wet locations and ground mounting
- 7-step MacAdam Ellipse binning for consistent color quality
- High power factor and low total harmonic distortion (THD)
- Mercury and UV free; RoHS-compliant components
- 5-year warranty covering light output, color stability, driver performance, and fixture finish
- Compatible with 0-10V dimming systems
- Compliant with Design Lights Consortium (DLC) Qualified Products List
- Buy American Act compliance available upon request
