Fan Support Boxes 2-1/8" Deep
SKU: #175973
Part: #CMB218
UPC: 751338871786
Fan Support Boxes 2-1/8" Deep
SKU: #175973
Part: #CMB218
UPC: 751338871786
Next day delivery
Description
Fan Support Boxes 2-1/8" Deep – Electrical Distributor Lighting Solutions
Fan Support Boxes 2-1/8" Deep by Southwire are designed for secure mounting of ceiling fans and light fixtures in new construction and remodel applications. Constructed from galvanized steel, these 4-inch diameter boxes provide a durable solution for electrical distributors and switchgear suppliers requiring reliable wire and cable management. The boxes feature a deep construction with a protective metal cover to prevent debris entry and wire damage, supporting fixtures up to 150 lbs and ceiling fans up to 70 lbs. UL listed and RoHS compliant, they incorporate side knockouts and an easy-to-use slide selector for #8 and #10 screw holes, ensuring versatile installation options.
Specifications
- Material: Galvanized Steel
- Diameter: 4 inches
- Depth: 2-1/8 inches
- Cubic Capacity: 21.5 CU-IN
- Number of Outlets: 2 Side, 3 Bottom
- Cable Entry: Knock Out
- Product Weight: 0.77 lbs
- Application: New Construction and Remodel
- Manufacturer: Southwire
- Manufacturer Part #: CMB218
- UL Listed
- RoHS Compliant
Features
- Protective metal cover eliminates debris entry and wire damage
- Easy-to-use slide select feature for #8 and #10 screw holes
- Energy-saving round design
- Side knockouts for cable entry flexibility
- Supports light fixtures up to 150 lbs
- Supports ceiling fans up to 70 lbs
