EZ-Path Series 33 Fire-Rated Pathway Extension Module
SKU: #49580
Part: #EZD33E
UPC: 730573000052
EZ-Path Series 33 Fire-Rated Pathway Extension Module
SKU: #49580
Part: #EZD33E
UPC: 730573000052
Next day delivery
Description
EZ-Path Series 33 Fire-Rated Pathway Extension Module - Fire Rated Pathway
The EZ-Path Series 33 Fire-Rated Pathway Extension Module is designed to extend the effective length of the Series 33 Fire Rated Pathway, a device that enables cables to penetrate fire-rated walls without the need for additional firestopping. This extension module increases the pathway length by 6 inches (152 mm) to accommodate thicker barriers and is compatible with all Series 33 accessories. Ideal for electrical distributors and switchgear suppliers managing high cable volume penetrations in fire-rated walls and floors.
Specifications
- Material: Galvanized Steel
- Color: Orange
- Dimensions: 6.5 in. (Length) x 3.25 in. (Width) x 3.75 in. (Height)
- Fire Rating: 1, 2, 3, and 4 Hour
- Mounting: Wall Plate
- Opening Type: Electrical Through-Penetrations, Cable Through-Penetrations
- Product Weight: 1.63 lbs
- Made in USA
- Country of Origin: United States
- Manufacturer Part #: EZD33E
Features
- Extends the effective length of Series 33 pathway for thicker fire-rated barriers
- Compatible with all Series 33 accessories for flexible installation
- Designed for fire-rated cable penetrations without the need for additional firestopping
- Constructed of heavy-gauge galvanized steel for durability and fire resistance
- Easy installation with wall plate mounting
- Supports high cable volume penetrations in electrical and communications applications
