Features

• Smooth, Rounded Integral Bushing in Each Hub Protects Conductor Insulation
• Accurately Tapped, Tapered Threads for Tight, Rigid Joints and Ground Continuity
• Removable Nipple in Male Sealing Fitting May be Used Interchangeably in Top or Bottom Hub
• Large Opening for Damming and Filling

Additional Information

• Size 3-1/4 Inch Length x 1-3/16 Inch Width
• Constructional Feature Explosionproof, Dust-Ignitionproof, Rain Tight
• Used On IMC/Rigid Conduit
• Application Hazardous Location
• Applicable Standard NEC/CEC

Specifications

• Type: Hub
• Turning Radius: 1-1/8 Inch
• Trade Size: 1/2 Inch
• Connection Type: Taper Female Threaded
• Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron
• Mounting Position: Vertical
• Enclosure: Class I Div 1 and 2 Group A B C D, Class II Div 1 and 2 Group E F G, Class III
• Approval: UL 886/E10444, CSA C22.2
• Series/Model: EY
