EXP CPLG 3/4IN, LENG 10IN GRAY Rigid Conduit Expansion Coupling

This PVC-coated XJG rigid conduit expansion coupling is designed to allow for the contraction and expansion of a conduit run without compromising the mechanical or bonding integrity of the raceway. Suitable for electrical distributors and lighting solutions requiring durable wire and cable protection, this coupling features a malleable iron body with zinc plating and an internal bonding jumper made of tinned copper braid. It enables linear movement in conduit runs while maintaining code compliance and installation efficiency.

Specifications

• Material: Iron (malleable iron with zinc plating)
• Color: Gray
• Length: 10.00 in (254.00 mm)
• Outside Diameter: 2.43 in (61.72 mm)
• Height: 2.75 in (69.85 mm)
• Movement: 4 in (101.60 mm)
• Internal Bonding Jumper: Tinned copper braid
• Packing Material: PTFE/Synthetic fiber
• UPC: 704508417529
• Manufacturer Part #: XJG24-G

Features

• Allows contraction and expansion of conduit runs without reducing mechanical or bonding integrity
• No disassembly required for installation, reducing tools and steps needed
• True internal bonding jumper eliminates the need for external grounding straps
• Tamper-proof internal jumper protected from environmental exposure
• Exceeds code requirements for long conduit runs to permit linear movement
• PVC exterior coating enhances corrosion resistance
