EQ LC ML 42S/42C 3PH 400A CU N3R
SKU: #19208
Part: #W4242ML3400CU
UPC: 783643335547
EQ LC ML 42S/42C 3PH 400A CU N3R
SKU: #19208
Part: #W4242ML3400CU
UPC: 783643335547
Next day delivery
Description
EQ LC ML 42S/42C 3PH 400A CU N3R Load Center
The Siemens EQ LC ML 42S/42C is a low voltage residential specialty load center designed for 3-phase electrical distribution in residential applications. This surface-mounted load center features a NEMA 3R outdoor-rated enclosure, suitable for weather-resistant installations. It supports up to 42 spaces and circuits with a 400 amp bus rating and a 65 kA interrupt rating, making it appropriate for robust residential electrical systems. This product is made in the USA and is ideal for electrical distributors and switchgear suppliers focusing on reliable residential lighting solutions and wire and cable management.
Specifications
- Application: Residential
- Amperage Rating: 400 A
- Bus Rating: 400A
- Interrupt Rating: 65 kA
- Number of Phases: 3
- Number of Spaces: 42
- Enclosure: Outdoor Type 3R
- Mounting: Surface
- Dimensions (W x H x L): 22.8 in x 8.2 in x 52 in
- Product Weight: 114.8 lbs
- Country of Origin: United States
- Made in USA: Yes
- Manufacturer Part #: W4242ML3400CU
Features
- Outdoor-rated NEMA 3R enclosure for weather protection
- Supports 3-phase, 4-wire configurations for versatile residential power distribution
- Copper bus standard for enhanced conductivity and durability
- Surface mounting for easy installation
