EQ LC MB 30S/30C 3PH 400A CU N1S
SKU: #310504
Part: #E3030MB3400SCU
UPC: 783643335387
EQ LC MB 30S/30C 3PH 400A CU N1S
SKU: #310504
Part: #E3030MB3400SCU
UPC: 783643335387
Next day delivery
Description
EQ LC MB 30S/30C 3PH 400A CU N1S Load Center
The Siemens EQ LC MB 30S/30C 3PH 400A CU N1S is a low voltage residential specialty load center designed for three-phase electrical distribution in residential applications. This surface-mounted load center provides a robust solution for electrical distributors and switchgear suppliers needing reliable wire and cable management and circuit protection. It features a 400 ampere bus rating and interrupt rating of 22 kA, supporting up to 30 circuit spaces with Siemens MB type circuit breakers.
Specifications
- Application: Residential
- Voltage Rating: 120/240 V
- Amperage Rating: 400 A
- Number of Phases: 3
- Number of Spaces: 30
- Circuit Breaker Type: MB
- Bus Rating: 400 A
- Interrupt Rating: 22 kA
- Mounting: Surface
- Enclosure: Indoor Type 1
- Dimensions (H x W x D): 54 in x 20 in x 8 in
- Product Weight: 105 lbs
- Country of Origin: United States
- Made in USA: Yes
Features
- UL listed for 60/75°C conductors
- Copper bus standard for reliable conductivity
- Factory installed lock on indoor enclosure for security
- Supports Siemens MB type circuit breakers for compatibility
- Surface mounting suitable for residential electrical installations
