EMERSON/AIR COMFORT IE-220 ACTIVE TRK FILTER 1PH 20A 240V DIN - Active Tracking Filter for Industrial Electrical Protection

The Emerson/Air Comfort IE-220 is a single-phase, 20 Amp, 240 Volt active tracking filter designed for critical industrial loads. It provides high-frequency noise filtering and surge suppression, ideal for protecting microprocessor-based products, industrial PLCs, OEM applications, and motion control systems. This device is suitable for electrical distributors and switchgear suppliers seeking reliable line conditioning and transient protection solutions.

Specifications

• Application: Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems
• Amperage Rating: 10 AMPS
• Frequency Rating: 47-63 Hz
• Mounting: DIN/Flange
• Connection: IEC 998 approved terminals
• Class: Category A Ringwave (6 kV, 200 A, 100 kHz)
• Environmental Conditions: Humidity 0 to 95%
• Product Weight: 1.45 lbs
• Manufacturer: Emerson/Air Comfort
• Manufacturer Part #: IE-220

Features

• Multi-staged design combining a unique hybrid clamping network with active tracking technology
• Surge current capacity of 45,000 Amps
• Transient protection in all modes: line to neutral, line to ground, and neutral to ground
• LED status indication and form C contact for remote indication
• ANSI/UL 1449 Third Edition Type 4, 1283 certified; CUL recognized; CE compliant
• DIN mountable enclosure for easy installation
• 10 year warranty
