EMERSON/AIR COMFORT IE-210 Active Tracking Filter 10A 240V DIN

The Emerson/Air Comfort IE-210 is a single-phase, 240V active tracking filter designed for critical industrial loads drawing up to 20 Amps of continuous current. It is ideal for protecting microprocessor-based products such as industrial PLCs, OEM applications, and motion control systems. This device is suitable for installation by electrical distributors and switchgear suppliers seeking reliable surge suppression and noise filtering solutions for wire and cable systems.

Specifications

• Application: Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems
• Amperage Rating: 5 AMPS
• Frequency Rating: 47-63 Hz
• Connection: IEC 998 approved terminals
• Mounting: DIN/Flange
• Class: Category A Ringwave (6kV, 200 A, 100 kHz)
• Environmental Conditions: Humidity 0 to 95%
• Product Weight: 0.8 lbs
• Manufacturer Part #: IE-210
• Manufacturer Name: Emerson/Air Comfort

Features

• Multi-staged design combining a hybrid clamping network with active tracking technology
• Surge current capacity of 45,000 Amps protecting line to neutral, line to ground, and neutral to ground
• DIN mountable enclosure for easy panel installation
• LED status indication and Form C contact for remote monitoring
• Meets ANSI/UL 1449 Third Edition Type 4, 1283, CUL recognized, and CE certifications
• Designed for an operating temperature range of -40¬∞C to +45¬∞C, derated linearly to 60% at +70¬∞C
• 10 year limited warranty against defects in material and workmanship
