ELECTRIFLEX 80132 1IN LIQUIDTIGHT FLEXIBLE STEEL CONDUIT JIC
SKU: #206707
Part: #80132
UPC: 782673801329
ELECTRIFLEX 80132 1IN LIQUIDTIGHT FLEXIBLE STEEL CONDUIT JIC
SKU: #206707
Part: #80132
UPC: 782673801329
Description
ELECTRIFLEX 80132 1IN LIQUIDTIGHT FLEXIBLE STEEL CONDUIT JIC - Liquidtight Flexible Steel Conduit
The ELECTRIFLEX 80132 is a 1-inch, liquidtight flexible steel conduit designed for electrical installations requiring motion, vibration, and bending. It provides good mechanical and moisture protection to enclosed conductors, making it suitable for industrial environments, machine tools, wet and oily locations, and outdoor applications due to its inherent UV resistance. This conduit is compatible with standard liquidtight connectors, serving electrical distributors and switchgear suppliers with reliable wire and cable protection solutions.
Specifications
- Manufacturer: ELECTRIFLEX
- Manufacturer Part #: 80132
- Material: Steel
- Color: Gray
- Length: 100 in
- Product Weight: 43 lbs per 100 ft
- Inner Core: Corrosion Resistant Plated Steel, 3/8” – 2” Squarelock Profile
- Liquidtight Jacket: Flexible PVC, Resistant to Oils and Mild Acids
- Working Temperature Range: -20°C to 80°C
- Certifications: Manufactured to UL 360 Dimensions, BS EN IEC 61386 Classification Code 443140650314, ARRA Certified
Features
- Good mechanical and moisture protection
- UV resistant PVC jacket suitable for outdoor use
- Compatible with standard liquidtight connectors
- Resistant to oils and mild acids
- Designed for motion, vibration, and bending applications
- Proudly made in the U.S.A.
