ELECTRIFLEX 21801 LA 11 BLACK 1/2IN. 100 FT.CT Flexible Steel Conduit

The ELECTRIFLEX 21801 LA 11 is a flexible steel conduit designed for electrical distributors and switchgear suppliers requiring durable and reliable wire and cable protection. This conduit offers outstanding protection against wet and oily conditions and is suitable for exposed or concealed installations in industrial, commercial, and utility applications. Its liquidtight PVC jacket ensures resistance to oils, mild acids, flame retardancy, and sunlight, making it ideal for a wide range of lighting solutions and electrical wiring systems.

Specifications

• Manufacturer: Electriflex
• Manufacturer Part #: 21801
• Material: Steel
• Color: Black
• Length: 100 in
• Product Weight: 32 lbs per 100 ft
• UPC: 782673218011
• Standard Length: 100 ft carton
• Inner Core: Hot Dipped Galvanized Steel, Squarelock profile with continuous bonding strip
• Liquidtight Jacket: Flexible PVC, resistant to oils and mild acids, flame retardant, sunlight resistant (UV)
• Temperature Range: -30°C to 80°C Dry, 60°C Wet, 70°C Oil
• Certifications: UL Listed (File # E29278), CSA Certified (File # LL18858), WEEE and RoHS Compliant, CE, NSF Certified Component

Features

• UL Listed and CSA Certified for safety and reliability
• Liquidtight flexible steel conduit suitable for wet, oily, and outdoor environments
• Flame retardant and sunlight resistant jacket for enhanced durability
• High impact and crush strength with resistance to many chemicals
• Permitted for direct burial and use in poured concrete
• Suitable for grounding conductor use in specified sizes per NEC Article 250.118(7)
• Compliant with NEC and ANSI/NFPA standards for industrial machinery and hazardous locations
• Available in machine tool gray and black colors, with custom colors available upon request
• Made in the USA with vertically integrated manufacturing and quality assurance
