Features

• Continuous, flicker-free dimming from 100% to 10%
• Integral sensor connection provides power for and responds to one occupancy sensor, one photo sensor, and one personal control input (infrared receiver or wallstation)
• Communicates status and sensor inputs over the EcoSystem digital link
• Programmed rapid start design ensures full rated lamp life while dimming and cycling
• Lamps turn on to any dimmed level without flashing to full brightness
• Low harmonic distortion throughout the entire dimming range
• Frequency of operation ensures that ballast does not interfere with infrared devices
• End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life
• Non-volatile memory restores all ballast settings after power failure
• Ballasts maintain consistent light output for linear lamp lengths (e.g., 4 ft [1.5 m], 3 ft [1 m], 2 ft [0.5 m] have same relative output)
• Maximize the benefits of a lighting management system
• Offers continuous, flicker-free 100 % to 10 % dimming; ideal for use where saving energy, increasing flexibility, and maximizing productivity are the goals of the lighting design
• Ultra-quiet operation
• Ballast maintain consistent light output for linear lamp lengths
• Protected from miswires of any input to power to control lead, or from lamp leads to each other and/or ground
• 100 % performance tested at factory
• Custom ballast factors available
• Design tool and specifications can be found at www.lutron.com/ballasttool

Standards and Certifications

• UL
• CSA
• ISO
• S Mark certified
• Class P thermal protected
• ANSI
• FCC

Specifications

• Amperage Rating: 0.28@120V/0.14@240V/0.12@277V
• Application: Lighting Control
• Ballast Factor: 1
• Number Of Lamps: 2
• Power Factor: Greater than 0.95
• Start Type: Programmed rapid
• Thermal Protection: Class P
• Total Harmonic Distortion: Less than 10%
• Type: Ballast
• Voltage Rating: 120/240/277 V
• Wattage: 14 W
• Width: 1.18 in
• Color: White
• Frequency Rating: 50/60 Hz
• Height: 1 in
• Lamp Type: T5 Linear fluorescent
• Length: 18 in
• Minimum Starting Temperature: 50 F
• Mounting: Fixture
