Features

• Explosionproof, Dust Ignitionproof, Water Tight
• Smooth, Rounded Integral Bushing in Each Hub Protects Conductor Insulation
• Accurately Tapped, Tapered Threads for Tight, Rigid Joints and Ground Continuity
• Heavy Duty Design Resists Mechanical Abuse
• Electrical Conductivity Equal to Rigid Conduit on a Similar Length Basis
• No Bonding Jumper Required
• Interior Insulating Liner Protects Conductors from Abrasion Under Vibrating Conditions

Additional Information

• Includes Insulating Liner
• Used On IMC/Rigid Metal Conduit
• Application Hazardous Location
• Applicable Standard NEC/CEC

Specifications

• Trade Size: 1/2 Inch
• Fitting Material: Bronze (Braid), Brass (Tube)
• Material: Bronze (Braid), Brass (Tube)
• End Type: (1) UNF Female Union, (1) Nipple
• Length: 15 Inch
• Enclosure: Class I Group A B C D, Class II Group E F G, Class III
• Approval: UL, CSA
• Series/Model: ECLK
