Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,125 A,65 kAIC,Two-pole,120/240 V,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load,Includes mounting kit
SKU: #162373
Part: #CV2125XMM
UPC: 786685706450
Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,125 A,65 kAIC,Two-pole,120/240 V,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load,Includes mounting kit
SKU: #162373
Part: #CV2125XMM
UPC: 786685706450
Total Price: $1,127.44 per each Sold in increments of 1 each
Description
Eaton Type CV Molded Case Circuit Breaker 125A Electrical Distributor
The Eaton Type CV Molded Case Circuit Breaker is designed for reliable circuit protection in residential and light commercial applications. It is commonly used by electrical distributors and switchgear suppliers in group metering setups. This two-pole, 125 ampere breaker supports 120/240 V systems and is rated for a 65 kA interrupting capacity, suitable for wire and cable installations with #6 - 4/0 aluminum or copper conductors. The breaker includes a mounting kit and supports a maximum load of #4/0 kcmil.
Specifications
- Amperage: 125 amperes
- Interrupting Capacity: 65 kAIC
- Number of Poles: 2
- Voltage Rating: 120/240 V
- Wire Size Compatibility: #6 - 4/0 Al/Cu
- Maximum Load: #4/0 kcmil
- Dimensions (WxHxL): 3.5 in x 5 in x 7.5 in
- Product Weight: 2.75 lbs
- Manufacturer Part Number: CV2125XMM
Features
- Two-pole molded case circuit breaker for residential group metering applications
- Available interrupting ratings of 42, 65, and 100 kAIC for protection at 120/240 Vac
- UL 489 and CSA 22.2 No. 5 compliant
- Replacement for Eaton CHH circuit breakers
- Includes mounting kit for easy installation
- Supports both aluminum and copper wire installations
