Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,100 A,65 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load
SKU: #162382
Part: #CV3100X
UPC: 786685704661
Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,100 A,65 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load
SKU: #162382
Part: #CV3100X
UPC: 786685704661
Next day delivery
Description
Eaton Type CV Molded Case Circuit Breaker 100A Electrical Protection
The Eaton Type CV Molded Case Circuit Breaker is designed for use in residential and light commercial electrical distribution systems. It provides reliable overcurrent protection for electrical circuits up to 100 amperes. This three-pole breaker supports a maximum load of #4/0 kcmil aluminum or copper wire, offering robust performance with a 65 kA interrupting capacity at 120/240 Vac. It is suitable for applications such as tenant main circuit breakers in group metering and as a replacement for Eaton CHH circuit breakers. The breaker is engineered to meet UL 489 and CSA 22.2 No. 5 standards, ensuring compliance with industry safety and performance requirements.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: CV3100X
- Amperage: 100 amperes
- Interrupting Capacity: 65 kAIC
- Number of Poles: Three-pole
- Wire Size Range: #6 - 4/0 Al/Cu
- Maximum Load Wire Size: #4/0 kcmil
- Dimensions (HxWxL): 5 in x 5 in x 7.5 in
- Product Weight: 4.4 lbs
Features
- Molded case construction for durable and safe electrical protection
- Available in both two- and three-pole configurations for flexible installation
- Complies with UL 489 and CSA 22.2 No. 5 standards
- Designed for use in group metering applications
- Replacement option for Eaton CHH circuit breakers
- Supports aluminum and copper wire sizes up to 4/0 kcmil
