Eaton Series G molded case circuit breaker, EG-frame, EG, Complete breaker, Fixed thermal, fixed magnetic trip, Three-pole, 20A, 600Y/347 Vac, 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, 35 kAIC at 600Y/347 Vac, Bolt-on, 50/60 Hz
SKU: #164823
Part: #EGH3020FFB
UPC: 786685381831
Eaton Series G molded case circuit breaker, EG-frame, EG, Complete breaker, Fixed thermal, fixed magnetic trip, Three-pole, 20A, 600Y/347 Vac, 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, 35 kAIC at 600Y/347 Vac, Bolt-on, 50/60 Hz
SKU: #164823
Part: #EGH3020FFB
UPC: 786685381831
Next day delivery
Description
Eaton Series G Molded Case Circuit Breaker – Electrical Distributor and Switchgear Supplier
The Eaton Series G molded case circuit breaker (EG-frame) is a robust electrical protection device designed for industrial and commercial power distribution applications. It is ideal for use in lighting solutions, wire and cable systems, and as part of switchgear assemblies. This three-pole breaker provides reliable overcurrent protection with fixed thermal and magnetic trip units, supporting electrical distributors in managing fault currents efficiently at voltages up to 600Y/347 Vac. Its compact design and high interrupting capacity make it suitable for demanding environments requiring consistent performance and safety.
- Manufacturer: Eaton
- Model Name: Eaton Series G molded case circuit breaker, EG-frame, Complete breaker
- Frame Type: EG
- Circuit Breaker Type: EG
- Poles: Three-pole
- Amperage Rating: 20 amperes
- Voltage Rating: 600Y/347 Vac
- Interrupting Capacity: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, 35 kAIC at 600Y/347 Vac
- Trip Type: Fixed thermal, fixed magnetic trip
- Frequency: 50/60 Hz
- Mounting Type: Bolt-on
- Enclosure Material: Stainless Steel
- Dimensions (HxWxD): 5.5 in x 3 in x 2.99 in
- Product Weight: 3.0 lbs
- Manufacturer Part Number: EGH3020FFB
Specifications
- Compact EG frame design suitable for a wide range of electrical distribution applications
- Fixed thermal and magnetic trip units provide precise and reliable overcurrent protection
- High interrupting capacity supports protection against high fault current levels, ensuring system safety
- Stainless steel enclosure material enhances durability and corrosion resistance
- Bolt-on mounting facilitates secure installation in switchgear and panelboards
- Compatible with Eaton’s broad line of molded case circuit breakers and accessories for flexible system integration
- Designed for use in lighting solutions, wire and cable distribution, and industrial electrical systems
- Certified to global standards ensuring reliable performance and safety compliance
