Eaton Series C electronic molded case circuit breaker, R-frame, RDC, Complete breaker, Digitrip 310 RMS, Electronic LSIG trip type, Three-pole, 2000A, 600 Vac, 65 kAIC at 480 Vac, 50 kAIC at 600 Vac, Without terminals
SKU: #168277
Part: #RDC320T36W
UPC: 786679548127
Eaton Series C electronic molded case circuit breaker, R-frame, RDC, Complete breaker, Digitrip 310 RMS, Electronic LSIG trip type, Three-pole, 2000A, 600 Vac, 65 kAIC at 480 Vac, 50 kAIC at 600 Vac, Without terminals
SKU: #168277
Part: #RDC320T36W
UPC: 786679548127
Description
Eaton Series C electronic molded case circuit breaker, 2000A electrical distributor solution
The Eaton Series C electronic molded case circuit breaker, R-frame type RDC, is designed for high-capacity electrical distribution and protection in industrial and commercial applications. This three-pole breaker features a Digitrip 310 RMS electronic LSIG trip unit, providing precise and reliable trip performance to protect wiring and equipment from overloads and short circuits. Rated for 2000 amperes and 600 Vac, it offers a high interrupt rating of 65 kiloamps at 480 Vac and 50 kiloamps at 600 Vac, suitable for demanding switchgear supplier requirements and wire and cable protection.
Specifications
- Amperage: 2000 amperes
- Voltage Rating: 600 Vac
- Interrupt Rating: 65 kiloamps at 480 Vac, 50 kiloamps at 600 Vac
- Poles: Three-pole
- Circuit Breaker Type: RDC
- Dimensions (W x H x L): 15.5 in x 15.5 in x 9.75 in
- Product Weight: 125 lbs
- Manufacturer Part #: RDC320T36W
Features
- Electronic Digitrip 310 RMS trip unit with LSIG trip type for advanced protection
- High interrupt rating ensures reliable short-circuit protection in heavy-duty applications
- Complete breaker without terminals for flexible installation
- Compatible with Eaton Series C family accessories and switchgear components
