Eaton Series C Complete Molded Case Circuit Breaker – Electrical Distributor and Switchgear Supplier

The Eaton Series C complete molded case circuit breaker, model FDC3175, is a thermal magnetic trip, F-frame breaker designed for reliable circuit protection in commercial and industrial electrical distribution systems. This three-pole breaker is engineered for use in lighting solutions, wire and cable protection, and as a key component in switchgear assemblies. It supports continuous current ratings up to 175 amperes, making it suitable for a wide range of electrical distributor applications.

Specifications

• Manufacturer: Eaton
• Model Number: FDC3175
• Frame Type: F
• Circuit Breaker Type: FDC (thermal magnetic trip)
• Amperage Rating: 175 amperes
• Poles: Three-pole
• Dimensions: 4.13 in (width) x 4.13 in (height) x 3.38 in (length)
• Product Weight: 4.5 lbs
• Interrupting Capacity: Rated for use at 240V, 480V, 600V AC, and 250V DC
• UPC: 786679019603

Features

• Thermal magnetic trip unit provides reliable protection against overloads and short circuits
• F-frame molded case design ensures durability and ease of installation in electrical distribution panels
• Three-pole configuration supports balanced three-phase power systems
• Compact dimensions facilitate integration into lighting solutions and switchgear supplier assemblies
• Factory sealed with UL489 listing and IEC compliance for safety and performance
• Suitable for use with copper and aluminum conductors with recommended torque specifications for terminal connections
• Includes manual operation handle with push-to-trip testing functionality for maintenance verification

Downloads and Links

• Installation Instructions for FDC Circuit Breakers and Molded Case Switches (IL 29C101I)
• Time Current Curves for Series C J-Frame Circuit Breakers (TD012033EN)
• Eaton Molded Case Circuit Breakers Product Page
