Eaton Series C complete molded case circuit breaker, J-frame, JD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 100 A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 50/60 Hz
SKU: #166681
Part: #JD3100
UPC: 786679013526
Eaton Series C complete molded case circuit breaker, J-frame, JD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 100 A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 50/60 Hz
SKU: #166681
Part: #JD3100
UPC: 786679013526
Next day delivery
Description
Eaton Series C Complete Molded Case Circuit Breaker – Molded Case Circuit Breaker
The Eaton Series C complete molded case circuit breaker, J-frame JD type, is designed for industrial and commercial electrical distribution applications. This three-pole breaker provides fixed thermal and fixed magnetic trip protection, suitable for use in power distribution and motor control systems. It supports electrical distributors and switchgear suppliers with reliable overcurrent protection at ratings up to 100 amperes and voltages up to 600 VAC and 250 VDC.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: JD3100
- Frame: J
- Amperage: 100 amperes
- Poles: Three-pole
- Voltage Rating: 600 VAC, 250 VDC
- Interrupting Capacity: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
- Frequency: 50/60 Hz
- Enclosure Material: Stainless Steel
- Dimensions (HxWxD): 10 in x 4.13 in x 4.06 in
- Product Weight: 8 lbs
- UPC: 786679013526
Features
- Fixed thermal and fixed magnetic trip unit for consistent overcurrent protection
- Designed for use in three-pole electrical circuits
- High interrupting capacity suitable for industrial power distribution
- Robust stainless steel enclosure for durability
- Compact J-frame design for efficient panel space utilization
