Eaton Series C complete molded case circuit breaker - GHB, Single-pole, 15A, 480Y/277 Vac

The Eaton Series C complete molded case circuit breaker, model GHBGFEP1015, is a G-frame, GHB type circuit breaker designed for reliable electrical protection in industrial and commercial applications. This single-pole breaker is rated for 15 amperes and supports 480Y/277 Vac and 125/250 Vdc electrical systems. It provides a fixed thermal and fixed magnetic trip type, ensuring precise and consistent interruption of electrical faults. Suitable for electrical distributors, lighting solutions providers, wire and cable installers, and switchgear suppliers, this breaker offers robust performance with a 14 kA interrupting capacity at 277 Vac and operates at 50/60 Hz frequency.

Specifications

• Manufacturer: Eaton
• Frame: G
• Circuit Breaker Type: GHB
• Amperage: 15 amperes
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Interrupting Capacity: 14 kAIC at 277 Vac
• Frequency: 50/60 Hz
• Dimensions (W x H x L): 1 in x 4 in x 2.63 in
• Product Weight: 1.5 lbs
• Manufacturer Part Number: GHBGFEP1015

Features

• Fixed thermal and fixed magnetic trip type for reliable circuit protection
• Single-pole design for dedicated circuit control
• Compact dimensions for easy integration into electrical panels
• Designed for use in both AC and DC electrical systems
• High interrupting capacity of 14 kA at 277 Vac to handle fault currents safely
