Eaton Series C GHB Molded Case Circuit Breaker - Electrical Protection

The Eaton Series C complete molded case circuit breaker, G-frame, GHB type, is a two-pole, fixed thermal and fixed magnetic trip breaker designed for branch circuit protection in electrical distribution systems. Rated at 25 amperes and suitable for 480Y/277 Vac and 125/250 Vdc applications at 50/60 Hz, this breaker provides reliable overload, short-circuit, and phase loss protection. It is ideal for electrical distributors and switchgear suppliers requiring compact, UL 489 listed circuit protection solutions.

Specifications

• Manufacturer: Eaton
• Model: GHB2025
• Frame: G
• Type: GHB Molded Case Circuit Breaker
• Amperage: 25 amperes
• Number of Poles: 2
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Frequency: 50 hertz
• Interrupt Rating: 65 kiloamps
• Dimensions (W x H x L): 2 in x 3 in x 2.63 in
• Weight: 1.21 lbs

Features

• Fixed thermal and fixed magnetic trip type for consistent protection
• UL 489 listed with a 65 kA interrupting rating for branch circuit protection
• Two-pole configuration suitable for 480Y/277 Vac and 125/250 Vdc systems
• Compact G-frame design reduces panel space requirements
• Reliable overload and short circuit protection for electrical distribution
• Compatible with standard Series C accessories
