Eaton Series C complete molded case circuit breaker, F-frame, HFD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 150 A, 600 Vac, 250 Vdc, Load side, 50/60 Hz
SKU: #166402
Part: #HFD3150
UPC: 786679175910
Eaton Series C complete molded case circuit breaker, F-frame, HFD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 150 A, 600 Vac, 250 Vdc, Load side, 50/60 Hz
SKU: #166402
Part: #HFD3150
UPC: 786679175910
Description
Eaton Series C Complete Molded Case Circuit Breaker F-Frame HFD 150 A
The Eaton Series C complete molded case circuit breaker, F-frame HFD type, is designed for reliable branch circuit and motor protection in industrial and commercial electrical systems. This three-pole breaker provides fixed thermal and fixed magnetic trip protection, suitable for both AC and DC applications up to 600 Vac and 250 Vdc. It is engineered to protect wiring and equipment from overloads, short circuits, and phase loss, making it an essential component for electrical distributors, lighting solutions providers, wire and cable installers, and switchgear suppliers.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: HFD3150
- Circuit Breaker Type: HFD
- Amperage: 150 amperes
- Voltage Rating: 600 Vac, 250 Vdc
- Poles: Three-pole
- Interrupt Rating: 100 kiloamps
- Frequency: 50/60 Hz
- Dimensions (W x H x L): 4.13 in x 4.13 in x 3.38 in
- Product Weight: 4.25 lbs
Features
- Fixed thermal and fixed magnetic trip type for consistent overload and short circuit protection
- Designed for load side installation
- UL 489 Listed with a 100 kA interrupting capacity at 240 Vac
- Reliable protection against phase loss and unbalance
- Compact F-frame design suitable for panel and switchgear integration
